Запчасти Case 621G (88.100.39[04]) - DIA KIT, FIELD SKID PLATE (88) - ACCESSORIES

1

48044365

FIELD SKID PLATE, Incl 2 - 10

KIT

1шт.

2

48044390

INSTRUCTION

SKID PLATES

1шт.

3

87597598

SKID PLATE

FRONT RIGHT

1шт.

4

87597597

SKID PLATE

FRONT LEFT

1шт.

5

896-15012

WASHER,13.5mm ID x 28mm OD x 4mm Thk

17шт.

6

892-11012

LOCK WASHER,M12

21шт.

7

627-12045

BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd

21шт.

8

48028903

PLATE

TRANS GUARD

1шт.

9

47400206

GUARD

ACCESS

1шт.

10

47857561

PLATE

SKID

1шт.
