Запчасти Case 1021G (10.501.010[01]) - EXHAUST SYSTEM (10) - ENGINE

1

47869601

MUFFLER

DOC

1шт.

2

47470179

EXHAUST SYSTEM PIPE

Engine to DOC

1шт.

3

47518527

PLATE

DOC Mounting

1шт.

4

47368254

GASKET,133.8mm ID x 154mm OD x 4.6mm Thk

2шт.

5

47390971

CLAMP,158mm ID, T - Bolt

2шт.

6

47399687

SECURING STRAP

2шт.

7

47476740

BRACKET

Exhaust Support

1шт.

8

47423212

CLAMP

Turbo to Exhaust System Pipe

1шт.

9

896-11010

WASHER,11mm ID x 21mm OD x 2.5mm Thk

7шт.

10

627-10020

BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd

3шт.

11

627-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd

2шт.

12

832-46410

NUT,M10 x 1.5, Cl 8

2шт.
