Запчасти Case 921F (27.110.01) - DIFFERENTIAL AXLE LOCK LINE (27) - REAR AXLE SYSTEM
№
Артикул
Название
Примечание
Количество
1
NSS
NOT SOLD SEPARAT
Bracket, Axle Differential
1шт.
2
84273235
END FITTING
FITTING, Hydraulic Differential Lock Return
1шт.
3
637-64236
O-RING,2.9mm Thk x 23.6mm ID, Cl 6, 90 Duro
1шт.
4
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
1шт.
5
84300976
LOCK VALVE
VALVE, Assembly Differential Lock
1шт.
6
700-315
ELBOW,45 Degree Elbow, 11/16" - 16 Male ORFS x M14 x 1.5 Male ORB
1шт.
7
700-304
ELBOW,90 Degree Elbow, 11/16" - 16 Male ORFS x M14 x 1.5 Male ORB
2шт.
8
700-157
HYD CONNECTOR,11/16" - 16 Male ORFS x M16 x 1.5 Male ORB
1шт.
9
84273193
HOSE ASSY.
HOSE, Differential Lock Valve Pressure
1шт.
10
379374A1
BLOCK
Tube Mounting
2шт.
11
NSS
NOT SOLD SEPARAT
Clamp Cover
2шт.
12
515-25508
CLAMP,2", Insul, 1/2" Bolt
1шт.
13
515-23238
CLAMP,15/16", Insul, 3/8" Bolt
1шт.
14
84266053
TUBE SPACER
Swivel
1шт.
15
84266050
CABLE TIE,384mm L, Polyamide
Cable Tie
2шт.
16
700-165
HYD CONNECTOR,11/16" - 16 Male ORFS x M12 x 1.5 Male ORB
1шт.
17
895-15010
WASHER,11mm ID x 24mm OD x 2mm Thk
2шт.
18
895-25006
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
4шт.
19
827-6060
BOLT,Hex, M6 x 60mm, Cl 10.9
2шт.
21
832-10410
NUT,M10 x 1.5, Cl 8
8шт.
23
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
4шт.
24
84273194
HOSE ASSY.
HOSE, Differential Lock Axle Pressure
1шт.
25
895-25008
WASHER,9mm ID x 24mm OD x 2mm Thk
2шт.
26
827-8035
BOLT,Hex, M8 x 1.25 x 35mm, Cl 10.9
1шт.
27
832-10408
NUT,M8 x 1.25, Cl 8.8
1шт.
28
84273191
HOSE ASSY.
HOSE, Differential Lock Valve Return
1шт.
29
84301377
HARNESS
HARNESS, Differential Lock Jumper
1шт.
30
84313033
DIFF LOCK SWITCH
SWITCH, Differential Lock Foot
1шт.
31
84266169
DIFF LOCK SWITCH
SWITCH, V Series Rocker
1шт.
32
864-6030
HEX SOC SCREW,M6 x 30mm, Cl 8.8
2шт.
33
515-2495
CLAMP,3/8", Insul, 7/16" Bolt
2шт.
