Запчасти Case 721F (10.414.01) - COVERS - DRIVE BELT (WITH AIR CONDITIONING) (10) - ENGINE

Схема запчастей Case 721F - (10.414.01) - COVERS - DRIVE BELT (WITH AIR CONDITIONING) (10) - ENGINE
7
4
8
5
6
3
home
4
2
1

Артикул

Название

Примечание

Количество

1

8501022

GUARD

Engine

1шт.

2

87016585

NUT,Spring, M6 x 1

Spring Multi-Thd M6

4шт.

3

86639038

BOLT,Hex, M6 x 1 x 25mm, Cl 10.9, Full Thd

Engine Guard Mtg, RH

2шт.

4

86517328

LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk

4шт.

5

86505530

BOLT,Hex, M6 x 1 x 20mm, Cl 10.9, Full Thd

2шт.

6

87528973

BRACKET

Engine Guard Mtg, LH

1шт.

7

86625253

WASHER,11mm ID x 24mm OD x 2mm Thk

2шт.

8

832-10410

NUT,M10 x 1.5, Cl 8

2шт.

Выбрано товаров: 8
