Запчасти Case 721F (55.100.12[03]) - HARNESS, MAIN CAB (55) - ELECTRICAL SYSTEMS

Схема запчастей Case 721F - (55.100.12[03]) - HARNESS, MAIN CAB (55) - ELECTRICAL SYSTEMS
17
9
home
7
2
10
4
14
6
55.100.12 01
1
1
16
18
12
19
3
13
1
8
1
5
16
15

Артикул

Название

Примечание

Количество

1

NSS

NOT SOLD SEPARAT

CONNECTOR

2шт.

2

371614A1

ELEC CONNECTOR,Female, 2 Pin

2-Cavity Plug

1шт.

3

388710A1

CONNECTOR, ELEC

CONNECTOR

1шт.

4

225351C1

ELEC CONNECTOR,Female, 6 Pin

6-Cavity Plug

1шт.

5

245482C1

ELEC CONNECTOR,2 Pin

2-Cavity Plug

1шт.

6

245483C1

ELEC CONNECTOR,Male, 2 Pin

2-Cavity Recepticle

1шт.

7

245480C1

ELEC CONNECTOR,1 Pin

1-Cavity Plug

1шт.

8

245715C1

ELEC CONNECTOR,4 Pin

4-Cavity Plug

1шт.

9

222136A1

ELEC CONNECTOR,Male, 2 Pin

2-Cavity Recepticle

1шт.

10

87635073

CONTACT HOUSING,Female, 10 Pole

10 Position Housing

1шт.

11

87419488

MULTIPOLE CONNECTOR,Female, 26 Pole

26 Way

1шт.

12

245486C1

ELEC CONNECTOR,4 Pin

4-Cavity Plug

1шт.

13

245487C1

ELEC CONNECTOR,Male, 4 Pin

4-Cavity Recepticle

1шт.

14

1964706C1

TERMINAL CONNECTOR

Ring

1шт.

15

NSS

NOT SOLD SEPARAT

SPLICE, 6-Way Delphi

2шт.

16

382391A1

MULTIPOLE CONNECTOR,Female, 10 Pin

10-Cavity Plug

4шт.

17

225253C1

CONNECTOR, ELEC

CONNECTOR 6-Cavity

1шт.

18

87410948

CONTACT HOUSING,Female, 26 Pole

26-Way Polarity

1шт.

19

NSS

NOT SOLD SEPARAT

CONNECTOR, Elobau

1шт.

Выбрано товаров: 19
