Запчасти Case 721F (39.100.03) - FRAME, REAR (39) - FRAMES AND BALLASTING

1

84300968

FRAME

Rear

1шт.

2

892-11012

LOCK WASHER,M12

4шт.

3

627-12040

BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd

6шт.

4

412067A1

LOCKING BAR

1шт.

5

126268A1

PIN,31.8mm OD x 108mm L

Articulation Lock

2шт.

6

A30338

PIN

Klik

2шт.

7

895-15012

WASHER,M12 x 28 x 2.5

4шт.

8

87333864

GUARD

Drive Shaft

1шт.

9

896-11012

WASHER,13.5mm ID x 24mm OD x 3mm Thk

2шт.

10

84260723

COVER PLATE

1шт.

11

844-10035

BOLT,Hex, M10 x 35mm, Cl 8.8

2шт.

12

47544915

FRAME

Not Illustrated, Incl 1 w/Decals, Euro

1шт.

12

47544916

FRAME

Not Illustrated, Incl 1 w/Decals, Spanish

1шт.

12

47544917

FRAME

Not Illustrated, Incl 1 w/Decals, French

1шт.

12

47544918

FRAME

Not Illustrated, Incl 1 w/Decals, North America

1шт.
