Запчасти Case 621F (10.400.02) - HYDRAULIC RESERVOIR FILTER (10) - ENGINE

1

L128515

STRAINER ELEMENT

Hydraulic Tank

2шт.

1

47575681

FILTER STRAINER

Hydraulic Tank, Start Year: 01-AUG-13

1шт.

used with newest Cooling Frame 47543184, Not Illustrated

1шт.

2

8500167

SEAL

1шт.

3

198825C1

GROMMET,15.88mm ID x 41.1mm OD x 26.9mm Thk

1шт.

4

700-307

ELBOW,90 Degree Elbow, 1-3/16" - 12 Male ORFS x M27 x 2 Male ORB

Incl 5 - 6

1шт.

5

238-6018

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

Face Seal

1шт.

6

637-64236

O-RING,2.9mm Thk x 23.6mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

7

217-445

PLUG,Hex Soc, 1-1/4" - 11-1/2 NPTF

1шт.

8

84382843

SEALING STRIP

Foam

1шт.

9

864-5016

HEX SOC SCREW,M5 x 16mm, Cl 8.8

2шт.

10

384774A1

LATCH

Flexible

1шт.

11

895-11005

WASHER,5.5mm ID x 10mm OD x 1mm Thk

2шт.

12

824-1405

NUT,M5, Cl 5

2шт.

13

8500133

OIL SEAL

Side

2шт.

14

87312068

OIL SEAL

Header

4шт.
