Запчасти Case 621F (88.055.01) - DIA KIT, REARVIEW CAMERA (88) - ACCESSORIES

1

84469128

KIT

Rearview Camera

1шт.

2

84469129

INSTRUCTION

1шт.

3

84336556

ARM

Monitor Mount

1шт.

4

84336673

PLATE

Access Adaptor Camera Monitor

1шт.

5

84377704

MONITOR

1шт.

6

84335794

BRACKET

Rearview Camera Mounting

2шт.

7

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

10шт.

8

84315054

VIDEO CAMERA

Color, BE890C

1шт.

9

627-6016

BOLT,Hex, M6 x 1 x 16mm, Cl 10.9, Full Thd

5шт.

10

829-1406

NUT,Hex, M6 x 1, Cl 10.9

3шт.

11

895-11004

WASHER,4.3mm ID x 9mm OD x 0.8mm Thk

3шт.

12

239225A1

SCREW,Phillips Drive, Pan HD, M4 x 0.7 x 12mm

4шт.

13

895-10004

WASHER,M4 x 9 x .8

1шт.

14

895-11005

WASHER,5.5mm ID x 10mm OD x 1mm Thk

8шт.

15

840-1516

SCREW,Pan, M5 x 16mm, Cl 4.8

4шт.

16

832-10405

NUT,M5 x .8, Cl 8

4шт.

17

84317692

WIRE HARNESS

BE-L Series

1шт.

18

297865A1

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

2шт.

19

297850A1

SCREW,Cross Pan Hd, M6 x 16

2шт.

20

60-4640T1

LATCH

1шт.

21

151-515

RIVET,Pop, .146" x .425"

2шт.

22

404882A1

SPRING NUT,M6

2шт.

23

86026822

GROMMET,3/4" ID x 1-3/8" OD x 7/16" Thk

1шт.

24

L11541

CABLE TIE,203.2mm L, Nylon

CABLE STRAP

15шт.

25

832-10406

NUT,M6 x 1, Cl 8

2шт.

26

121410A1

FUSE,5A, Mini, Tan

1шт.

27

84336424

TUBE SPACER

Monitor Mount Bar

2шт.

28

84336541

BAR

Monitor Mount Grey

1шт.

29

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

2шт.

30

827-8090

BOLT,Hex, M8 x 1.25 x 90mm, Cl 10.9

2шт.
