Запчасти Case 521F (88.100.55[07]) - DIA KIT - ISOLATION MOUNT (88) - ACCESSORIES

1

47508156

KIT

Isolation Mount PL10-20 CE Grey, Incl 2 - 17

1шт.

2

47690126

INSTRUCTION

Isolation Mount

1шт.

3

47508112

BRACKET

Light Front LH CE Grey

1шт.

4

47508105

BRACKET

Light Front RH CE Grey

1шт.

5

896-11012

WASHER,13.5mm ID x 24mm OD x 3mm Thk

8шт.

6

627-12040

BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd

4шт.

7

832-10412

NUT,M12 x 1.75, Cl 8

4шт.

8

47532797

MOUNT

BC-1120-1

8шт.

9

47533441

PLATE

Isomount CE Grey

4шт.

10

140042

WASHER,11mm ID x 34mm OD x 3mm Thk

16шт.

11

47508199

MOUNT

Front Light CE Grey

2шт.

12

895-15010

WASHER,11mm ID x 24mm OD x 2mm Thk

8шт.

13

627-10040

BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd

8шт.

14

832-10410

NUT,M10 x 1.5, Cl 8

8шт.

15

368055A1

LIGHT,Halogen, 24V, 70W, Clear

1шт.

16

368056A1

LIGHT,Halogen, 24V, 70W, Clear

1шт.

17

248-2376

GROMMET,5/8" ID x 1 1/4" Groove Dia, Str Cut

2шт.
