Запчасти Case 1121F (90.160.08) - COVERS, SIDE AND REMOTE DRAIN (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case 1121F - (90.160.08) - COVERS, SIDE AND REMOTE DRAIN (90) - PLATFORM, CAB, BODYWORK AND DECALS
1
6
2
3
5
home
7
4
3

Артикул

Название

Примечание

Количество

1

84408204

COVER

Side Cover, Left Side, Used Without Axle Coolers

1шт.

1

84408204

COVER

Side Cover, Left Side, Used With Axle Coolers

1шт.

2

84408207

COVER

Side Cover, Right Side, Used Without Axle Coolers

1шт.

2

84408210

COVER

Side Cover, Right Side, Used With Axle Coolers

1шт.

3

844-10040

BOLT,Hvy Hex, M10 x 40mm, Cl 8.8

6шт.

4

84398943

COVER

Engine Drain Case

1шт.

5

844-8020

BOLT,Hvy Hex, M8 x 20mm, Cl 8.8

1шт.

6

87646822

BRACKET

Retainer, Fill Cap Lock

1шт.

7

L11541

CABLE TIE,203.2mm L, Nylon

CABLE STRAP 55MM

1шт.

Выбрано товаров: 9
