Запчасти Case 1021F (10.202.01[02]) - AIR CLEANER INSTALLATION (10) - ENGINE

1

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

9шт.

2

832-10410

NUT,M10 x 1.5, Cl 8

6шт.

3

627-8020

BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd

10шт.

4

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

4шт.

5

827-10045

BOLT,Hex, M10 x 1.5 x 45mm, Cl 10.9

1шт.

6

84331787

BRACKET, SUPPORTING

Air Cleaner

1шт.

7

627-8012

BOLT,Hex, M8 x 1.25 x 12mm, Cl 10.9, Full Thd

4шт.

8

87305403

SPACER,13.51mm ID x 19.05mm OD x 17.5mm Thk

3/4 tube; .688"

1шт.

9

214-1528

HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm, W/ Liner

3шт.

10

827-8045

BOLT,Hex, M8 x 1.25 x 45mm, Cl 10.9

1шт.

11

896-11008

WASHER,9mm ID x 17mm OD x 2mm Thk

2шт.

12

832-10408

NUT,M8 x 1.25, Cl 8.8

2шт.

13

90-7640T1

VALVE

Check

1шт.

14

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

1шт.

15

896-15008

WASHER,9mm ID x 21mm OD x 2.5mm Thk

1шт.

16

84261853

BRACKET, SUPPORTING

Check Valve

1шт.

17

627-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd

2шт.

18

84261848

AIR HOSE

Aspirator Engine

1шт.

19

90-7639T1

CLAMP

Valve

1шт.

20

84402116

FOAM

Air Cleaner

1шт.

21

84402117

FOAM

Air Cleaner

1шт.

22

84402118

FOAM

Air Cleaner

1шт.
