Запчасти Case 1021F (88.025.03) - AXLE COOLER LINE, HD (88) - ACCESSORIES

1

48051949

KIT, AXLE COOLER LINE, FRONT HD, Incl 2 - 28

KIT

1шт.

2

48051950

INSTRUCTION

1шт.

3

84489948

TUBE

AXLE RETURN REAR

1шт.

4

47359732

BRACKET

REAR AXLE TUBES

1шт.

5

84419537

HYD TUBE

SUCTION STD AXLE

1шт.

6

84477201

TUBE

REAR AXLE SUCTION

1шт.

7

84385136

CHECK VALVE

1шт.

8

84489946

HOSE ASSY.,19.05mm ID x 673.4mm L, SAE 100R1

RR, SUCTION AXLE

1шт.

9

515-24190

CLAMP,3/4", Insul, 7/16" Bolt

1шт.

10

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

4шт.

11

832-10410

NUT,M10 x 1.5, Cl 8

1шт.

12

84489947

HOSE ASSY.,15.88mm ID x 640mm L, SAE 100R1

RR, RETURN AXLE

1шт.

13

84576119

TUBE

RETURN AXLE FRONT HD

1шт.

14

47488378

BRACKET

SUPPORT FRONT AXLE TUBES

1шт.

15

87526208

CHECK VALVE

1шт.

16

84489957

HOSE ASSY.,19.05mm ID x 2345mm L, SAE 100R1

FR, SUCTION AXLE

1шт.

17

48022331

HOSE

RETURN AXLE

1шт.

18

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

2шт.

19

84391508

BRACKET, SUPPORTING

AXLE RH

2шт.

20

84362173

BRACKET, SUPPORTING

AXLE RH

2шт.

21

627-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd

2шт.

22

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

2шт.

23

515-23159

CLAMP,5/8", Insul, 3/8" Bolt

2шт.

24

832-10408

NUT,M8 x 1.25, Cl 8.8

1шт.

25

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

1шт.

26

700-343

ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x M18 x 1.5 Male ORB

4шт.

27

701-342

ELBOW,90 Degree Elbow, 1-3/16" - 12 Male ORFS x 1-3/16" - 12 Female ORFS

1шт.

28

515-23254

CLAMP,1", Insul, 3/8" Bolt

1шт.
