Запчасти Case 1021F (88.025.02) - AXLE COOLER LINE, STANDARD (88) - ACCESSORIES

1

48051947

AXLE COOLER LINE, Incl 2 - 30

KIT

1шт.

2

48051948

INSTRUCTION SHT, AXLE COOLER LINE

INSTRUCTION

1шт.

3

84483049

TUBE

RETURN AXLE FRONT STD

1шт.

4

84419537

HYD TUBE

SUCTION STD AXLE

2шт.

5

84477201

TUBE

REAR AXLE SUCTION

1шт.

6

47359732

BRACKET

SUPPORT REAR AXLE TUBES

1шт.

7

515-23190

CLAMP,3/4", Insul, 3/8" Bolt

1шт.

8

84489948

TUBE

AXLE RETURN REAR

1шт.

9

700-343

ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x M18 x 1.5 Male ORB

4шт.

10

84489947

HOSE ASSY.,15.88mm ID x 640mm L, SAE 100R1

RR, RETURN AXLE

1шт.

11

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

1шт.

12

84489950

BRACKET

SUPPORT FRONT AXLE TUBES

1шт.

13

84385136

CHECK VALVE

2шт.

14

84489946

HOSE ASSY.,19.05mm ID x 673.4mm L, SAE 100R1

RR, SUCTION AXLE

1шт.

15

701-342

ELBOW,90 Degree Elbow, 1-3/16" - 12 Male ORFS x 1-3/16" - 12 Female ORFS

2шт.

16

515-25317

CLAMP,1 1/4", Insul, 1/2" Bolt

1шт.

17

515-23159

CLAMP,5/8", Insul, 3/8" Bolt

2шт.

18

84483053

HOSE ASSY.,19.05mm ID x 2123.6mm L, SAE 100R1

FR, AXLE SUCTION

1шт.

19

87302487

SPACER,13.8mm ID x 21.3mm OD x 10.3mm L

1шт.

20

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

5шт.

21

627-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd

2шт.

22

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

2шт.

23

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

1шт.

24

827-10040

BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd

1шт.

25

84483051

HOSE ASSY.,19.05mm ID x 561mm L, SAE 100R1

FR, AXLE SUCTION

1шт.

26

515-23254

CLAMP,1", Insul, 3/8" Bolt

1шт.

27

48022331

HOSE

RETURN AXLE

1шт.

28

84362173

BRACKET, SUPPORTING

4шт.

29

832-10408

NUT,M8 x 1.25, Cl 8.8

1шт.

30

832-10410

NUT,M10 x 1.5, Cl 8

1шт.
