Запчасти Case 921E (09-78) - AIR CONDITIONING - CONDENSER (09) - CHASSIS

1

87375118

CONDENSER

1шт.

2

76047002

SENSOR

A/C

1шт.

2a

76047001

RECEIVER-DRYER

A/C Dryer, has a place for the pressure switch on the dryer

1шт.

2a

295006A1

RECEIVER-DRYER

A/C Dryer, does not have a place for the pressure switches on the dryer.

1шт.

2b

76053044

CLAMP BRACKET

1шт.

2c

76047004

BRACKET

1шт.

3

87365703

HOSE ASSY.

1056mm ( 42in ); Condenser To Dryer

1шт.

4

87365701

HOSE ASSY.

2391mm ( 94in ); Compressor To Condenser

1шт.

5

87517078

HOSE ASSY.

2150mm ( 85in ); Cab To Compressor

1шт.

6

87517077

HOSE ASSY.

2740mm ( 108in ); Dryer To Cab

1шт.

7

87573983

SLIDE

Condenser

1шт.

8

627-8030

BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd

2-3шт.

9

896-11008

WASHER,9mm ID x 17mm OD x 2mm Thk

2-3шт.

10

87377023

SPACER

4шт.

11

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

3шт.

12

627-10030

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd

2шт.

13

515-23175

CLAMP,11/16", Insul, 3/8" Bolt

1-2шт.

14

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

8шт.

15

627-10040

BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd

4шт.

16

829-1410

NUT,M10 x 1.5, Cl 10.9

4шт.

17

87378625

RAMP

Condenser Catch

2шт.

18

838-3818

PIN,M8 x 18, Coiled

4шт.

19

627-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd

2шт.

20

L129282

LINCH PIN

1шт.

21

128307A1

CHAIN (CE)

1шт.

22

L300295

RETAINER

1шт.

23

627-10020

BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd

1шт.

24

87395886

SEAL

1шт.

25

L101181

CLAMP,0.75" D Clamping pipes x 2

1шт.

26

L11541

CABLE TIE,203.2mm L, Nylon

CABLE STRAP

1шт.

27

827-10050

BOLT,Hex, M10 x 1.5 x 50mm, Cl 10.9

1шт.

28

L126936

SPACER

1шт.
