REF
INSTRUCTION
EUROPE ONLY
1шт.
1
87348711
PLATE
Electrical Mounting
1шт.
2
87351908
SOLENOID SWITCH
Starting
1шт.
3
87315269
BREAKER
Circuit, 105A Auto Reset; If Used
1шт.
15
895-11006
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
8-16шт.
16
627-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 10.9, Full Thd
4шт.
17
832-10406
NUT,M6 x 1, Cl 8
5-7шт.
18
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
5шт.
19
827-8060
BOLT,Hex, M8 x 1.25 x 60mm, Cl 10.9
3шт.
20
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
If Used
2шт.
21
832-10408
NUT,M8 x 1.25, Cl 8.8
1шт.
23
82024562
SPACER,8.5mm ID x 18mm OD x 31.6mm L
3шт.
24
87353999
COVER
Relay
1шт.
25
627-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
2шт.
31
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
34
515-23206
CLAMP,13/16", Insul, 3/8" Bolt
3шт.
37
404635A1
SPACER
1шт.
39
827-8020
BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd
2шт.
41
827-6050
BOLT,Hex, M6 x 50mm, Cl 10.9
1шт.
43
87350064
CABLE
Cab B+; If Used
1шт.
44
87350066
CABLE
Starter Relay
1шт.
45
87318627
MODULE
Power Relay
1шт.
48
87327335
FUSE,20 Amp
32V 20A
1шт.
49
87327346
FUSE,40A, Green
32V 40A
1шт.
54
1546485C1
RELAY,24V
Power
1шт.
59
829-1406
NUT,Hex, M6 x 1, Cl 10.9
2шт.
