Артикул
Название
Примечание
Количество
1
76303033
CONSOLE
RH
1шт.
2
REF
INSTRUCTION
STORAGE BOX, See Figure 09-53
1шт.
3
REF
INSTRUCTION
COOL BOX, See Figure 09-53
1шт.
4
87667054
TRIM PANEL
Rear, Replaces 76303425
1шт.
5
87667053
TRIM PANEL
Rear, Replaces 76303422
1шт.
6
840-1630
SCREW,Pan, M6 x 30mm, Cl 4.8
8шт.
7
895-11006
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
11шт.
8
847-3616
SERRATED SCREW,Sl Truss, M6 x 16mm, Cl 10.9
4шт.
9
86514457
SCREW,Phil Pan Hd, M6 x 35mm, Cl 4.8, Full Thd
M6 x 35, Cl 4.8; Replaces 86503049 Used On Some Models
2шт.
10
239105A1
SCREW,Cross Pan Hd, M6 x 20mm
Replaces 14778414 Screw Used On Some Models
1шт.
11
404287A1
INSERT,M6
M6
5-11шт.
11a
86013769
NUT
Threaded Insert, M6, Open; Replaces 404287A1 Insert
6шт.
12
833-40306
SPRING NUT,M6, U
2шт.
13
76303040
CONSOLE
Front
1шт.
14
614-6012
BOLT,Hex, M6 x 1 x 12mm, Cl 8.8, Full Thd
3шт.
15
353-412
PLUG,Dome, 1.093" hole, Nylon
Cab Trim, Not Illustrated
3шт.
16
353-404
PLUG,Dome, .500" hole, Nylon
5шт.
