Запчасти Case 621E (09-80) - AIR CONDITIONING HOSES (09) - CHASSIS

1

87440551

A/C HOSE

Cab to Compressor; 3715 mm (146 in); Incl. Ref. 1A, For Low Pressure Switch See 16

1шт.

1a

128485A1

O-RING,1.78mm Thk x 14mm ID, 70 Duro

Not Illustrated

1шт.

2

87629992

HOSE

Compressor to Condensor; 3658 (144 in); Incl. Refs. 2A, 2B

1шт.

2a

128484A1

O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro

Condensor End; Not Illustrated

1шт.

2b

128485A1

O-RING,1.78mm Thk x 14mm ID, 70 Duro

Compressor End; Not Illustrated

1шт.

3

87651217

HOSE

Dryer to Cab; 1052 (41 - 13/32 in); Incl. Ref. 3A

1шт.

3a

452005C1

O-RING

Dryer End; Not Illustrated

1шт.

4

FAR8602469

HOSE

Condensor to Dryer; 2000 mm (79 in); Incl. Ref. 4A

1шт.

4a

128483A1

O-RING,1.78mm Thk x 7.65mm ID, 70 Duro

Not Illustrated

1шт.

5

76047001

RECEIVER-DRYER

A/C Dryer, has a place for the pressure switch on the dryer

1шт.

5

295006A1

RECEIVER-DRYER

A/C Dryer, does not have a place for the pressure switches on the dryer.

1шт.

5a

76047002

SENSOR

A/C

1шт.

5b

76053044

CLAMP BRACKET

1шт.

5c

76047004

BRACKET

1шт.

6

895-18010

WASHER,10.5mm ID x 18mm OD x 1.6mm Thk

3шт.

7

832-10410

NUT,M10 x 1.5, Cl 8

2шт.

8

31-1081

CLAMP

2шт.

9

379374A1

BLOCK

1шт.

10

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

1шт.

11

832-10408

NUT,M8 x 1.25, Cl 8.8

1шт.

12

198826C1

GROMMET,19.05mm ID x 41.1mm OD x 26.9mm Thk

1шт.

13

198825C1

GROMMET,15.88mm ID x 41.1mm OD x 26.9mm Thk

1шт.

14

515-22254

CLAMP,1", Insul, 5/16" Bolt

If Used

1шт.

14

515-23254

CLAMP,1", Insul, 3/8" Bolt

If Used

1шт.

15

87720368

CAP

A/C Hose

1шт.

16

122579A1

SWITCH, A/C LOW PRES

Not Shown, Low Pressure

1шт.

17

232948A1

SWITCH, A/C HIGH PRE

Not Shown, High Pressure

1шт.
