Запчасти Case 521E (02-39) - COOLING SYSTEM - ENGINE (02) - ENGINE

87752850

ENGINE

4 Cylinder 4.5L Turbo, Tier III; Replaces 87579398; Includes Figures 02-09 - 02-13, 02-15 - 02-41, 03-05 - 03-11; Incl. Refs. 1 - 5

1шт.

1

2852325

SCREW

M10 x 80

3шт.

2

2854072

SEALING RING,Square, 5.16mm Thk x 50.17mm ID

2шт.

3

2852392

SUPPORT

Incl. Ref. 4

1шт.

4

4895576

DOWEL

2шт.

5

2852394

TUBE,44 mm ID, 48 mm OD, 55 mm Length

Water Inlet

1шт.
