Запчасти Case 721D (08-01) - HYDRAULIC RESERVOIR - ASSEMBLY (08) - HYDRAULICS

1

87342555

FRAME

Cooling

1шт.

1

87342555

FRAME

Cooling, Includes 90 Degree Barb Fitting For New Brake Pump Style

1шт.

2

384774A1

LATCH

1шт.

3

864-5016

HEX SOC SCREW,M5 x 16mm, Cl 8.8

2шт.

4

895-11005

WASHER,5.5mm ID x 10mm OD x 1mm Thk

2шт.

5

824-1405

NUT,M5, Cl 5

2шт.

6

8602535

SCREEN

No Longer Used

1шт.

6

87430715

SCREEN

Replaces 8602535

1шт.

7

8602476

PROP

1шт.

8

895-15010

WASHER,11mm ID x 24mm OD x 2mm Thk

3шт.

9

733-3220

COTTER PIN,M3.2 x 20

1шт.

10

895-15006

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

1шт.

11

832-10406

NUT,M6 x 1, Cl 8

1шт.

12

892-11008

LOCK WASHER,8mm ID

9шт.

13

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

7шт.

14

8500164

HOSE

Sight Gauge; Upper; Cut from 32-080T1

1шт.

15

8500165

HOSE

1800 mm (70-7/8 in); Sight Gauge; Lower; Cut from 32-080T1

1шт.

16

8602016

BRACKET

Sight Gauge

1шт.

17

8606005

CAP

TANK, If Used; Incl Ref. 17A

1шт.

17a

87757884

FILLER CAP

Hydraulic Tank

1шт.

18

8606006

VALVE, CHECK

Hydraulic Tank

1шт.

19

86521965

ELBOW,90 Degree, 3/8"-18 Female x 3/8"-18 Male

1шт.

20

86988366

SIGHTGLASS

Gauge; Includes Hardware

1шт.

21

131-141

PUSH-ON NUT,.74", Push-on

2шт.

22

198826C1

GROMMET,19.05mm ID x 41.1mm OD x 26.9mm Thk

2шт.

23

214-1406

HOSE CLAMP,#06, 0.44" - 0.78", Type F Worm

4шт.

24

214-1704

HOSE CLAMP,#04, 0.25" - 0.62", Type M Worm

If Used

1шт.

25

31-2940

FUEL HOSE

55 mm (2-3/16 in); Breather; Cut from 32-012

1шт.

26

379587A2

GASKET

1шт.

27

515-22190

CLAMP,3/4", Insul, 5/16" Bolt

2шт.

28

515-23143

CLAMP,9/16", Insul, 3/8" Bolt

1шт.

29

627-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

7шт.

30

832-10408

NUT,M8 x 1.25, Cl 8.8

8шт.

31

833-40408

NUT,M8, U

6шт.

32

892-11008

LOCK WASHER,8mm ID

9шт.

33

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

7шт.

34

L125836

FITTING

2шт.

35

892-11012

LOCK WASHER,M12

4шт.

36

627-12040

BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd

4шт.

37

895-15012

WASHER,M12 x 28 x 2.5

4шт.
