Запчасти Case 721D (06-30) - AXLE, REAR - HUB, DISC BRAKES (06) - POWER TRAIN

8602380

REAR AXLE

REAR, Limited Slip; Incl. Figure(s) 06-28 - 06-32; New Wheel End Assembly S/N 431 997 & After

1шт.

87361214R

REMAN-REAR AXLE

721D S/N 431 997 & After (1/03-), Reman For New P/N: 8602380

1шт.

87361214C

CORE-REAR AXLE

Return Number

1шт.

87361214

REAR AXLE

Limited Slip; Incl. Figure(s)06-28 - 06-32; Oil Filled; Components Same As 8602380 Except Wheel End Assembly

1шт.

87361214R

REMAN-REAR AXLE

721D (1/03-)

1шт.

87361214C

CORE-REAR AXLE

Return Number

1шт.

8603698

FINAL DRIVE

FINAL REDUCTION GEARBOX Incl. 1 - 15; Also Includes Figure 06-29; Axle S/N 431996 & Before

1шт.

8605591

REMAN-WHEEL END ASSY

REMANUFACTURED AXLE/FINAL REDUCTION GEARBOX - NA Only

1шт.

8605592

CORE-WHEEL END ASSY

Return Number, AXLE/ FINAL REDUCTION GEARBOX - NA Only

1шт.

87441324

FINAL DRIVE

FINAL REDUCTION GEARBOX Gear Reduction Unit; Incl. 1 - 15; Also Includes Figure 06-29; Axle S/N 431997 & After

1шт.

87361216

FINAL DRIVE

FINAL REDUCTION GEARBOX Replaces 87441324

1шт.

87363354

REMAN-WHEEL END ASSY

REMANUFACTURED AXLE, NA Only

1шт.

87363352

CORE-WHEEL END ASSY

Return Number, AXLE, NA Only

1шт.

1

8603165

PISTON

Brake

1шт.

2

8605314

SEAL,298mm ID x 310mm OD x 8mm Thk

1шт.

3

8603577

RING

1шт.

4

8605315

SEAL

1шт.

5

8603579

RING

1шт.

6

8603580

SNAP RING

1шт.

87365252

REPAIR KIT

Brake Disc; Incl. Refs. 7, 8A, 8B

1шт.

7

8603581

BRAKE DISC

Inner

4шт.

7

87341835

BRAKE DISC

Replaces 8603581

4шт.

8

8603582

BRAKE PLATE

Outer; Used in (4) Plate Brake Assembly; If Used

4шт.

8a

8603582

BRAKE PLATE

Used with Ref 8B; Used in (5) Plate Brake Assembly; If Used

3шт.

8b

87441328

PLATE,2mm Thk

Used with Ref 8A; Used in (5) Plate Brake Assembly; If Used

2шт.

9

8603163

PIN

6шт.

10

8603583

SEAL

24шт.

11

8603584

BELLEVILLE WASHER

42шт.

12

8603162

SHIM

1шт.

13

8603788

SNAP RING

6шт.

14

8603585

SNAP RING

1шт.

15

8603796

ROLL PIN,6mm OD x 20mm L

6шт.
