Артикул
Название
Примечание
Количество
1
700-101
HYD CONNECTOR,11/16" - 16 Male ORFS x M14 x 1.5 Male ORB
Incl. 2, 3
1шт.
1a
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
1b
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
Face Seal
1шт.
2
380912A1
GROMMET
2шт.
3
701-329
ELBOW,90 Degree Elbow, 9/16" - 18 Male ORFS x 9/16" - 18 Female ORFS
M6 fc sl x swl; Incl. 3A
4шт.
3a
238-6011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
Face Seal
1шт.
4
700-153
HYD CONNECTOR,9/16" - 18 Male ORFS x M14 x 1.5 Male ORB
M8 fc sl x 14 orb; Incl. 4A, 4B
4шт.
4a
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
4b
238-6011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
Face Seal
1шт.
5
8501047
ACCUMULATOR
Component Parts Not Serviced Separately
1шт.
6
391859A1
VALVE, CHECK
Incl. 6A
1шт.
6a
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
7
701-422
TEE,11/16" - 16 Male ORFS x 11/16" - 16 Male ORFS x 11/16" - 16 Female ORFS
Incl. 7A
1шт.
7a
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
Face Seal
2шт.
8
701-434
TEE,11/16" - 16 Male ORFS x 11/16" - 16 Male ORFS x 11/16" - 16 Female ORFS
Incl. 8A
1шт.
8a
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
Face Seal
1шт.
9
392059A1
HOSE ASSY.
1294 mm lg; Hydraulic Tank
1шт.
10
392058A1
HOSE ASSY.
2453 mm lg; Pressure
1шт.
11
366517A1
HOSE ASSY.
2627 mm lg; Third Spool; Left Hand
1шт.
12
366518A1
HOSE ASSY.
2707 mm lg; Third Spool; Right Hand
1шт.
13
366519A1
HOSE ASSY.
2737 mm lg; Fourth Spool; Left Hand
1шт.
14
366520A1
HOSE ASSY.
2752 mm lg; Fourth Spool; Right Hand
1шт.
15
87308338
HOSE ASSY.
1шт.
16
701-909
NUT,11/16" - 16
M10; Inc 14A
1шт.
16a
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
7/8 ID x 1/16; Face Seal
1шт.
18
366514A1
HOSE ASSY.
2471 mm lg; Tilt; Left Hand
1шт.
19
366513A1
HOSE ASSY.
2557 mm lg; Lift; Right Hand
1шт.
20
366515A1
HOSE ASSY.
2547 mm lg; Tilt; Right Hand
1шт.
21
190119A1
COUPLING
Incl. 19A
1шт.
21a
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
Face Seal
1шт.
22
401526A1
HOSE PROTECTION,60mm ID x 1200mm L
1шт.
23
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
1шт.
Выбрано товаров: 33
