Запчасти Case 521D (02-08) - COOLING SYSTEM - MOTOR, DRIVE (REVERSIBLE FAN DRIVE) (02) - ENGINE

1

8605147

VALVE

Pressure Relief; See Figure 02-09; Replaces 445495A1 Valve Used In Production

1шт.

2

700-306

ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x M22 x 1.5 Male ORB

Incl. 3, 4

1шт.

3

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

Face Seal

1шт.

4

637-63193

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

5

701-361

ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x 1" - 14 Female ORFS

Incl. 6

1шт.

6

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

Face Seal

1шт.

8

700-162

HYD CONNECTOR,13/16" - 16 Male ORFS x M22 x 1.5 Male ORB

Incl. 9,10

1шт.

9

637-63193

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

10

238-6014

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

Face Seal

1шт.

11

440832A1

HOSE ASSY.

1626,5 mm; Forward

1шт.

12

700-326

ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x M22 x 1.5 Male ORB

Incl. 13, 14

2шт.

13

238-6014

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

Face Seal

1шт.

14

637-63193

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

15

700-103

HYD CONNECTOR,1" - 14 Male ORFS x M22 x 1.5 Male ORB

Incl. 16,17

1шт.

16

637-63193

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

17

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

Face Seal

1шт.

18

376179A2

HOSE ASSY.

1935 mm; Reverse

1шт.

19

700-387

ELBOW,45 Degree Elbow, 1-3/16" - 12 Male ORFS x M27 x 2 Male ORB

Incl. 20, 21

1шт.

20

238-6018

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

Face Seal

1шт.

21

637-64236

O-RING,2.9mm Thk x 23.6mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

22

400337A1

MOTOR, HYDRAULIC

Fan Drive; Includes 8604978 Seal Kit, 8604520 Shaft Seal; M12 Drain Port On Top; No Longer Available, Order 87426773 Motor (Ref 22A), 700-378 Elbow (Ref 34) and 87427292 Hose On Figure 07-05

1шт.

22a

87426773

HYDRAULIC MOTOR,GEAR, 14 CC

Fan Drive; Includes 87426795 Seal Kit; M14 Drain Port On Side

1шт.

22a

87426773R

REMAN-HYD MOTOR

1шт.

22a

87426773C

CORE-MOTOR HYDRAULIC

Return Number

1шт.

23

408003A3

HOSE ASSY.

809 mm; Valve Supply

1шт.

24

407750A1

BRACKET

1шт.

25

827-8120

BOLT,Hex, M8 x 1.25 x 120mm, Cl 10.9

3шт.

26

895-11008

WASHER,9mm ID x 16mm OD x 1.6mm Thk

3шт.

27

832-10408

NUT,M8 x 1.25, Cl 8.8

3шт.

28

827-12050

BOLT,Hex, M12 x 1.75 x 50mm, Cl 10.9

2шт.

29

896-15012

WASHER,13.5mm ID x 28mm OD x 4mm Thk

13,5 x 28 x 4 mm

4шт.

30

832-10412

NUT,M12 x 1.75, Cl 8

2шт.

31

700-303

ELBOW,90 Degree Elbow, 9/16" - 18 Male ORFS x M12 x 1.5 Male ORB

90 deg; 9/16 fc sl x M12 Or; Incl 32, 33; Used With 400337A1 Motor (Ref 22); If Used

1шт.

32

238-6011

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

Face Seal

1шт.

33

637-63093

O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro

Boss Seal

1шт.

34

700-378

ELBOW,90 Degree Elbow, 9/16" - 18 Male ORFS x M14 x 1.5 Male ORB

90 deg; 9/16 fc sl x M14 Or; Incl. 35, 36; Used With 87426773 Motor (Ref 22A); If Used

1шт.

35

637-63113

O-RING,2.2mm Thk x 11.3mm ID, Cl 6

1шт.

36

238-6011

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

Face Seal

1шт.

37

382375A2

SWITCH

Rocker; Fan Reverser

1шт.
