Запчасти Case 921C (04-31) - MOUNTING - BACKUP ALARM (04) - ELECTRICAL SYSTEMS

European Models -JEE0126215

1шт.

1

REF

INSTRUCTION

Harness, Rear Chassis, See Figure 04-17

1шт.

2

324436A2

HARNESS

Rear Lamp, Replaces 324436A1

1шт.

3

515-23159

CLAMP,5/8", Insul, 3/8" Bolt

Use existing hardware

2шт.

4

832-10410

NUT,M10 x 1.5, Cl 8

3шт.

5

419792A1

SENSOR

Coolant Level, Replaces 143417A2, 143417A3

1шт.

6

515-21127

CLAMP,1/2", Insul, 1/4" Bolt

2шт.

7

627-6025

BOLT,Hex, M6 x 1 x 25mm, Cl 10.9, Full Thd

2шт.

8

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

2шт.

9

829-1406

NUT,Hex, M6 x 1, Cl 10.9

M6; 10.9

2шт.

10

D121972

ALARM

Backup

1шт.

11

627-6025

BOLT,Hex, M6 x 1 x 25mm, Cl 10.9, Full Thd

4шт.

12

495-21031

WASHER,1/4"

5/16 x 3/4 x 1/16

4-8шт.

13

832-10406

NUT,M6 x 1, Cl 8

4шт.

14

253186A2

HARNESS

Ground

2шт.

15

253347A1

NUT,Hex, M10 x 1.5

M10 - 1,5, Brass

3шт.

16

242101A5

HARNESS

Cab Main, Replaces 242101A2, 242101A3, 242101A4, -JEE0125745

1шт.

16

429188A2

HARNESS

Cab Main, Replaces 429188A1, JEE0125746-

1шт.

17

374433A3

SWITCH

Backup Alarm Disable, Replaces 284291A1

1шт.

18

445786A1

WIRE HARNESS

Jumper

1шт.

19

1276117C1

SELF-TAP SCREW,Cross Pan Hd, 1/4" x 3/4"

1/4 x 3/4

2шт.

Note: See Figure 04-33 for rear combination lamps and page 4-35 for license plate lamp

1шт.

Nota : Voir les page 4 - 33 pour les feux combinés arrière et page 4 - 35 pour l'éclairage de la plaque d'immatriculation.

1шт.

Nota: Consultar las página 4-33 y para las luces de combinación traseras y la página 4-35 para la luz de la matrícula.

1шт.
