Запчасти Case 821C (07-07) - HYDRAULICS BRAKE, MAIN (07) - BRAKES

Accumulator Valve to Return Port On Orifice Valve Block Tube

1шт.

All Models -JEE0126215

1шт.

1

313362A1

VALVE

Brake Accumulator Valve, Accumulator Charging, See Page(s) 7-31

1шт.

2

218-5070

HYD CONNECTOR,3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB

Includes 3, For Auxiliary Steering, See Page(s) 5-35

1шт.

3

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

4

317862A1

TUBE,12.7 mm OD, 530, 7 mm Length

Brake Accumulator Charging Valve

1шт.

5

515-23127

CLAMP,1/2", Insul, 3/8" Bolt

Attaches to 314931A1 Bracket

1шт.

6

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

1шт.

7

895-15010

WASHER,11mm ID x 24mm OD x 2mm Thk

1шт.

8

832-10410

NUT,M10 x 1.5, Cl 8

1шт.

9

895-18010

WASHER,10.5mm ID x 18mm OD x 1.6mm Thk

1шт.

Accumulator Valve to Return Port On Orifice Valve Block Tube

1шт.

All Models -JEE0126215

1шт.

10

317920A1

HOSE ASSY.

1079 mm (42-1/2 in), Attaches to Bottom Port on 108748A1 Manifold

1шт.

11

515-21222

CLAMP,7/8", Insul, 1/4" Bolt

2шт.

12

627-6020

BOLT,Hex, M6 x 1 x 20mm, Cl 10.9, Full Thd

1шт.

13

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

2шт.

14

832-10406

NUT,M6 x 1, Cl 8

1шт.

15

L18337

CABLE TIE,9.95"-12.1" lg

CABLE STRAP , 15 in

1шт.
