Запчасти Case 621C (03-002) - CONTROLS THROTTLE, FOOT (03) - FUEL SYSTEM

1

247726A1

SUPPORT

DIPSTICK

1шт.

2

515-23127

CLAMP,1/2", Insul, 3/8" Bolt

1шт.

3

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

1шт.

4

895-18010

WASHER,10.5mm ID x 18mm OD x 1.6mm Thk

2шт.

5

832-10410

NUT,M10 x 1.5, Cl 8

1шт.

6

293385A1

SUPPORT

BRACKET

1шт.

7

627-12025

BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd

2шт.

8

892-11012

LOCK WASHER,M12

2шт.

9

225619A1

BALL JOINT

1шт.

10

495-11028

WASHER,1/4", SAE

(9/32 x 5/8 x 1/16")

1шт.

11

231-4644

LOCK NUT,1/4"-28, GB

1шт.

12

293270A1

LEVER

1шт.

13

D124939

SPRING

1шт.

14

627-6016

BOLT,Hex, M6 x 1 x 16mm, Cl 10.9, Full Thd

2шт.

15

892-11006

LOCK WASHER,M6

2шт.

16

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

2шт.

17

302253A1

CABLE

1шт.

18

259529A1

CLAMP BRACKET

U-BOLT, includes hardware

1шт.

19

234124A2

PLATE

Replaces: P/N 234124A1

1шт.

20

295157A1

PEDAL ASSY.

See figure 3-5

1шт.

21

627-8065

BOLT,Hex, M8 x 1.25 x 65mm, Cl 10.9, Full Thd

1шт.

22

829-1408

NUT,Hex, M8 x 1.25, Cl 10.9

1шт.

23

827-6030

BOLT,Hex, M6 x 30mm, Cl 10.9

No longer used, Order: P/N 827-6040

3шт.

23

827-6040

BOLT,Hex, M6 x 40mm, Cl 10.9

3шт.

24

895-11006

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

3шт.

25

827-8040

BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9

Replaces existing fuel pump support hardware

2шт.
