Запчасти Case 621 (8-62) - REMOTE LOADER CONTROL CIRCUIT, TWO LEVERS WITH THREE SPOOL VALVE (08) - HYDRAULICS

1

L116443

VALVE

ASSEMBLY - control, remote, single lever, parts list Figure 8-78

1шт.

2

L123917

VALVE

ASSEMBLY - control, remote, auxiliary, single lever, parts list Figure 8-82

1шт.

3

140-114

SCREW,Cross Pan Hd, 1/4" - 20 x 1"

Cross Pan Hd, 1/4"-20 NC x 1"

8шт.

4

1339947C1

LARGE PLATE

PLATE - mounting, remote control

1шт.

5

218-5135

ELBOW,45 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB

- 45 degree, adjustable

2шт.

7

76349

PLUG,9/16" - 18 ORB

if used Hex Hd, 9/16"-18 ORB

1шт.

Ref. 15, "B" hose, goes to the upper rear port of Ref. 1, remote control valve, on some models, and to the upper left-hand port of Ref. 2, auxiliary remote control valve, on some models. Connection at the hose separator is the same for either routing.

1шт.

9

218-5057

HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB

CONNECTOR - straight

10шт.

11

1339965C1

HOSE,9.53mm ID x 419.1mm L, SAE 100R1

- 16-1/2" (419 mm) long, remote control to hose separator

4-6шт.

12

1339968C1

HOSE ASSY.

HOSE - 16-3/4" (425 mm) long, auxiliary remote control to hose separator, no longer available, order item 11, 1339965C1

1шт.

13

1339966C1

HOSE ASSY.

HOSE - 17" (432 mm) long, auxiliary remote control to hose separator, no longer available, order item 11, 1339965C1

1шт.

14

1339962C1

HOSE,9.53mm ID x 254mm L, SAE 100R1

- 10 " (254 mm) long, auxiliary remote control to remote control

2шт.

15

1339964C1

HOSE,9.53mm ID x 501.7mm L, SAE 100R1

- 19-7/8" (502 mm) long, remote control and/or auxiliary remote control to pressure reducing valve

1-2шт.

Ref. 15, "B" hose, goes to the upper rear port of Ref. 1, remote control valve, on some models, and to the upper left-hand port of Ref. 2, auxiliary remote control valve, on some models. Connection at the hose separator is the same for either routing.

1шт.

16

1339967C1

HOSE ASSY.

HOSE - 22-1/2" (572 mm) long, remote control to hydraulic tank, no longer available, order item 15, 1339964C1

1шт.

17

1339969C1

LARGE PLATE

SEPARATOR - hose, loader control

1шт.

18

218-1254

LOCK NUT,Blkhd, 9/16"-18

NUT, LOCK, Blkhd, 9/16"-18

8шт.

19

218-673

FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree

FIT STL BULKHD .375MJ .375MJ

8шт.

20

43-12512

SCREW,Cross Flat Hd, 1/4"-20 x 3/4"

- machine, flat head Phillips, 1/4 NC x 3/4 inch

6шт.

21

113-4

BOLT,Hex, 1/4" - 20 x 1", Gr 5

3шт.

22

1977321C1

DECAL

- loader control, not shown, see Figure 9-100, item 17

1шт.

23

76349

PLUG,9/16" - 18 ORB

if used Hex Hd, 9/16"-18 ORB

1шт.

25

218-5057

HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB

CONNECTOR - straight

1шт.

6

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, Elbow

1шт.

8

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, Plug

1шт.

10

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, Connector

1шт.

24

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, Plug

1шт.

26

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, Connector

1шт.
