Запчасти Case 845B (06-12[01]) - REAR AXLE, TANDEM (06) - POWER TRAIN

1

84405528

GASKET,1.5mm Thk

4шт.

2

75326525

GASKET,315mm ID x 331mm OD x 7.5mm Thk

2шт.

3

84385694

BREATHER

1шт.

4

87476417

BLOCK

2шт.

5

11106231

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9

40шт.

6

10516871

LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk

40шт.

7

70912768

PLUG

1шт.

8

75266712

COVER PLATE

4шт.

9

87677039

COVER

2шт.

10

84405529

GASKET,1.5mm Thk

2шт.

11

87665240

FINAL DRIVE

FINAL REDUCTION GEARBOX

1шт.

12

75266741

COVER

1шт.

13

73161784

GASKET,1.5mm Thk

1шт.

14

70920416

PLUG

3шт.

15

84379010

OIL SEAL,363mm ID x 375mm OD x 9mm Thk

2шт.

16

75246450

BUSHING,350mm ID x 362.5mm OD x 80mm L

2шт.

17

75266759

FLANGE

2шт.

18

80710

LUBE NIPPLE,1/8” – 27 Dryseal PTF

4шт.

19

75253782

RING,380mm ID x 440mm OD x 3mm Thk

2шт.

20

15981231

BOLT,Hex, M16 x 1.5 x 65mm, Cl 10.9

48шт.

21

10517273

WASHER

48шт.

22

75258149

COVER

2шт.

23

15988531

BOLT,Hex, M20 x 1.5 x 70mm, Cl 10.9, Full Thd

48шт.

24

87667591

CHAIN,54 Links x 50.8mm = 2743.2mm

2шт.

25

73155650

RING,363mm ID x 440mm OD x 3mm Thk

2шт.

26

75325418

SHIM,444mm ID x 502mm OD x 0.45mm Thk

14шт.

27

75325420

SHIM,444mm ID x 502mm OD x 0.15mm Thk

4шт.

28

75325419

SHIM,444mm ID x 502mm OD x 0.18mm Thk

4шт.
