Артикул
Название
Примечание
Количество
1
REF
INSTRUCTION
PUMP hydraulic Assy
1шт.
Page 08-66
1шт.
2
70188771
GASKET,0.79mm Thk
1шт.
3
11112431
SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd
2шт.
4
10517071
LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk
4шт.
5
75323722
HYD CONNECTOR
1шт.
6
214-2122
CLAMP,39.62mm - 45.97mm
8шт.
7
75325657
HYDRAULIC HOSE,32.00 mm ID x 390.00 mm, SAE 100R4
1шт.
8
87362914
HYD CONNECTOR
1шт.
9
75325055
HOSE,19mm ID x 750mm L, SAE 100R2
1шт.
10
70901652
PLUG
1шт.
11
75325032
HYD CONNECTOR
1шт.
12
70919134
PLUG
1шт.
13
87394148
HOSE,19mm ID x 440mm L, SAE 100R2
1шт.
14
70921228
HYD CONNECTOR
Includes item 15
1шт.
15
70921214
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
1шт.
16
70921217
HYD CONNECTOR
Includes item 17
1шт.
17
70921206
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
19
73164378
PIPE
1шт.
19
84169787
RIGID TUBE,22.90 mm ID x 25.40 mm OD
, Start Serial: N9AF05153
1шт.
20
75325497
HYDRAULIC HOSE,25.40 mm ID x 900.00 mm, SAE 100R3
Flexible
1шт.
21
87372829
CLAMP,1.40" - 1.56"
4шт.
22
87376433
HOSE,25.4mm ID x 600mm L, SAE 100R3
1шт.
23
87363148
HYD CONNECTOR
Includes item 24
1шт.
24
14438285
O-RING,29.5mm ID x 3.0mm
1шт.
27
87382507
OIL COOLER
1шт.
28
87376364
SUPPORT
LH
1шт.
29
87376821
SEAL
RH
1шт.
30
16044331
SCREW,Hex, M8 x 1.25 x 55mm, Cl 10.9
4шт.
31
12646704
WASHER,8.15mm ID x 20mm OD x 2mm Thk
4шт.
32
75223894
SPACER,12.4mm ID x 16mm OD x 40mm L
4шт.
Выбрано товаров: 31
