Запчасти Case 885 (06.28[00]) - REAR AXLE CLARK - OIL COOLING (06) - POWER TRAIN

1

75249382

HOSE,51.00 mm ID x 85.00 mm, SAE 20R4 D1

1шт.

2

70921913

HOSE CLIP

8шт.

3

73163941

TUBE

1шт.

4

75221770

ELBOW,51mm ID x 85mm L, SAE 20

2шт.

5

75257806

RIGID TUBE,47 mm ID, 50 mm OD, 795 mm Length

1шт.

6

11107631

SCREW,Hex, M10 x 70mm, Cl 10.9

Graziano

2шт.

6

12577221

LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 10, ZND

Clark

2шт.

7

10516879

LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk

2шт.

8

10516879

LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk

2шт.

9

75257785

TUBE

1шт.

10

16043431

SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd

3шт.

11

12645031

WASHER,8.45mm ID x 21mm OD x 3mm Thk

3шт.

12

73158847

ELBOW,38.1mm ID x 152mm L, SAE 20R4-D2

1шт.
