Артикул
Название
Примечание
Количество
1
15219531
BOLT
1шт.
2
10520201
WASHER,16.4mm ID x 28mm OD x 3mm Thk
1шт.
3
75327641
SUPPORT
1шт.
4
70919135
HYD CONNECTOR
Includes item 5
1шт.
5
70921885
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
6
87756948
HYD CONNECTOR
Includes item 7
1шт.
7
14438285
O-RING,29.5mm ID x 3.0mm
1шт.
8
87372829
CLAMP,1.40" - 1.56"
2шт.
9
87755864
FLEXIBLE HOSE
1шт.
11
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
4шт.
12
70927155
CLIP
1шт.
13
16043231
SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd
1шт.
14
75327777
GROMMET
3шт.
15
87644617
RIGID TUBE,14 mm ID x 19 mm OD
1шт.
16
814-8140
BOLT,Hex, M8 x 1.25 x 140mm, Cl 8.8
4шт.
17
10516679
LOCK WASHER,Helical Spring, 8.20mm ID x 14.80mm OD x 2.20mm, C72, ZNM
4шт.
18
14496531
WASHER,8.4mm ID x 17mm OD x 1.6mm Thk
4шт.
19
REF
INSTRUCTION
VALVE fan reverse
1шт.
Page 08-068
1шт.
20
87673400
FLEXIBLE HOSE
2шт.
21
86900673
HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB
Includes item 22
2шт.
23
75326973
HOSE ASSY.
1шт.
24
REF
INSTRUCTION
MOTOR hydraulic
1шт.
Page 08-072
1шт.
25
87644618
RIGID TUBE,14 mm ID x 19 mm OD x 417, 180 mm L
1шт.
26
86637976
CLAMP,19mm, Coat, 8.7mm Bolt Hole, P Type
2шт.
27
87678515
SUPPORT
1шт.
28
16104121
NUT,M8 x 1.25, Cl 10
2шт.
29
86579697
ELBOW,90 Degree, 1-3/16"-12 ORFS x M27 x 2.0 ORB
Includes item 30
2шт.
30
14457981
O-RING,1.049" ID x 0.103" Width
2шт.
31
14496531
WASHER,8.4mm ID x 17mm OD x 1.6mm Thk
2шт.
32
16043131
BOLT,Hex, M8 x 1.25 x 14mm, Cl 10.9, Full Thd
2шт.
33
14507887
PLUG,25mm ID, 39mm OD
1шт.
34
87678230
RIGID TUBE,230, 159 mm L
1шт.
Выбрано товаров: 36
