Артикул
Название
Примечание
Количество
1
70927541
SCREW
1шт.
2
70923905
ELBOW
Includes item 3
2шт.
3
70921349
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
2шт.
4
70928808
3 WAY CONNECTION
2шт.
5
70921279
ELBOW
1шт.
6
16043831
SCREW,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd
2шт.
7
10730301
WASHER,8.15mm ID x 17mm OD x 2mm Thk
2шт.
8
70623355
COLLAR
2шт.
9
70921402
ELBOW
Includes item 10
1шт.
10
70921349
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
2шт.
11
75255796
HYDRAULIC HOSE
2шт.
12
70922457
HYD CONNECTOR
Includes item 13
2шт.
13
70921349
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
2шт.
14
75248980
RIGID TUBE
1шт.
15
75248981
RIGID TUBE
1шт.
16
70630753
WASHER
4шт.
17
75320494
FLEXIBLE HOSE
1шт.
18
70677004
WASHER,7.14mm ID x 15.88mm OD x 3.42mm Thk
1шт.
19
70929344
CLAMP
1шт.
20
75248982
RIGID TUBE,9.7 mm ID, 12.7 mm OD, 304, 169 mm Length
1шт.
21
75248979
RIGID TUBE
1шт.
22
75251155
FLEXIBLE HOSE
2шт.
23
70929457
O-RING
Includes item 24
2шт.
24
70921349
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
2шт.
25
11107331
SCREW,Hex, M10 x 55mm, Cl 10.9
2шт.
26
11701721
NUT,M10, Cl 10
2шт.
27
70922457
HYD CONNECTOR
Includes item 28
2шт.
28
70921349
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
2шт.
29
75255798
HOSE,9.5mm ID x 405mm L, SAE 100R2
2шт.
30
70921409
HYD CONNECTOR
2шт.
31
REF
INSTRUCTION
VALVE retainer
2шт.
Page 08-108
1шт.
32
75251173
FLEXIBLE HOSE
1шт.
Выбрано товаров: 33
