Запчасти Case 865 (07.05[00]) - BRAKE PEDAL (07) - BRAKES

1

75214658

BOOT

1шт.

2

75324598

PEDAL

1шт.

3

16043431

SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd

4шт.

4

10519621

WASHER,8.15mm ID x 17mm OD x 2mm Thk

12шт.

5

75249809

COVER

1шт.

6

16043631

SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd

1шт.

7

12645031

WASHER,8.45mm ID x 21mm OD x 3mm Thk

1шт.

8

16100821

NUT,M8, Cl 10

2шт.

9

10516679

LOCK WASHER,Helical Spring, 8.20mm ID x 14.80mm OD x 2.20mm, C72, ZNM

2шт.

10

75249805

SUPPORT

1шт.

11

75249949

BRAKE SERVO

1шт.

12

16044131

BOLT,Hex, M8 x 45mm, Cl 10.9

2шт.

13

10119440

PLUG,M18 x 1.5 x 16, Brass

1шт.

14

75252200

PLATE

1шт.
