Запчасти Case 845 (03-06[01]) - TRANSMISSION CHARGE SENSOR (03) - FUEL SYSTEM

1

87754958

LEVER

1шт.

2

87421807

JOINT ASSY.

2шт.

3

84126503

TIE-ROD

1шт.

4

832-10405

NUT,M5 x .8, Cl 8

2шт.

5

87739469

SENSOR

1шт.

6

87753617

SUPPORT

1шт.

7

14496431

WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk

4шт.

8

10516471

LOCK WASHER

4шт.

9

627-6020

BOLT,Hex, M6 x 1 x 20mm, Cl 10.9, Full Thd

4шт.

10

14496531

WASHER,8.4mm ID x 17mm OD x 1.6mm Thk

3шт.

11

10516671

LOCK WASHER

3шт.

12

16043431

SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd

3шт.

13

495-31022

WASHER,#10

2шт.

14

225-14210

NUT,#10-32

2шт.
