/ / / / / / / / (67A00001447[001]) - ELECTRICAL EQUIPMENTS - SIDE PANEL
Запчасти Case 340 (67A00001447[001]) - ELECTRICAL EQUIPMENTS - SIDE PANEL (13) - Electrical System / Decals
![Схема запчастей Case 340 - (67A00001447[001]) - ELECTRICAL EQUIPMENTS - SIDE PANEL (13) - Electrical System / Decals](https://partsell.ru/storage/images/casece/1089842.png)
6
2
3
3
9
10
1
5
2
7
4
8
1
89500409303
HOUSING
1шт.
2
8998199849
BOLT
M4 x 12
10шт.
3
8917032877
SCREW,M6 x 25mm
M6 x 25
6шт.
4
8900101322
NUT
M6
4шт.
5
8998454560
MANIPULATOR
1шт.
6
8917234910
ELEC. TERMINAL PIN
2шт.
7
89500409170
MANIPULATOR
1шт.
8
89500409376
SWITCH
REAR
1шт.
9
89500409377
SWITCH
FRONT
1шт.
10
8941200583
SOCKET
12V
1шт.
