(61A00020560[001]) - MUDGUARDS, REAR (P.I.N HHD0335BN8PG58147 AND AFTER) (84281115)

Запчасти Case 335B (61A00020560[001]) - MUDGUARDS, REAR (P.I.N HHD0335BN8PG58147 AND AFTER) (84281115) (10) - Cab/Cowlings

Схема запчастей Case 335B - (61A00020560[001]) - MUDGUARDS, REAR (P.I.N HHD0335BN8PG58147 AND AFTER) (84281115) (10) - Cab/Cowlings
2
5
1
4
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

89500425194

SUPPORT

2шт.

2

89500425193

SUPPORT

2шт.

3

89500425191

MUDFLAP

2шт.

4

8900115555

BOLT,M8 x 30mm

22шт.

5

8900115122

NUT

22шт.
