Запчасти Case 330 (43A00010773[03]) - STEERING SYSTEM - HYDRAULIC CIRCUIT (09) - Implement / Hydraulics / Frame / Brakes

1

89500401919

PIPE

1шт.

2

8900030684

SEALING RING

SEALRING

1шт.

3

8900056265

BOLT

M8 x 40

8шт.

4

8900956220

LOCK WASHER

8шт.

5

8900145012

COLLAR

8шт.

6

8900193954

FLEXIBLE HOSE

1шт.

7

8900190248

BOLT

3/8" unc x 1 3/83"

4шт.

8

8900001049

LOCK WASHER

4шт.

Serial Number : Until HHD0000308

1шт.

8

8900001031

LOCK WASHER

4шт.

Serial Number : HHD0000309 And After

1шт.

9

8900191136

FLANGE

2шт.

10

8900011009

SEALING RING

SEALRING

1шт.

11

8900125076

HOSE CLIP

4шт.

12

8900193197

HOSE

1шт.

13

89500405811

SUPPORT

1шт.

Serial Number : Until HHD0000308

1шт.

13

89500405811

SUPPORT

1шт.

Serial Number : HHD0000309 And After

1шт.

14

8900115589

BOLT

M10 x 30

2шт.

15

8900140777

NUT

2шт.

16

89500405053

INLET MANIFOLD

2шт.

Serial Number : Until HHD0000308

1шт.

16

89500410000

PIPE

2шт.

Serial Number : HHD0000309 And After

1шт.

17

89500400134

GASKET

4шт.

18

8960710037

HYDRAULIC PUMP

1шт.

Serial Number : Until HHD0000308

1шт.

18

89500409411

HYDRAULIC PUMP

1шт.

Serial Number : HHD0000309 And After

1шт.

19

8900119987

BOLT

M12 x 40

4шт.

20

8900115529

LOCK WASHER

4шт.

21

8900001398

WASHER

4шт.

22

8900003227

BOLT,M12 x 1.75 x 40mm

M12 x 40 x 1.75

4шт.

23

8900040256

COLLAR

4шт.

24

89500400285

SUPPORT

1шт.

25

8900001048

BOLT

M10 x 30 x 1.5

1шт.

26

8900956837

COLLAR

2шт.

27

8900025351

NUT

M10

1шт.

28

89500405669

PLUG

1шт.
