Запчасти Case 220 (011) - COWLING (12) - Chassis/Attachments

P1133882

SCREW

/BOLT, M12 x 35

8шт.

P828507

WASHER

13 x 7 x 25

8шт.

P104158

END FITTING

2шт.

P104158

END FITTING

2шт.

P35730

SPLIT PIN/SAFETY PIN

SPLIT PIN/SAFET, 4 x 20

2шт.

P832320

GRAB RAIL, 15 x 21

2шт.

P3143881

SHUTTER

FLAP

1шт.

P3443841

SHUTTER

FLAP, no longer sold

1шт.

P1726145

REINFORCEMENT

1шт.

P35003

WASHER

2шт.

P3143895

SHUTTER

FLAP, replaced by

1шт.

P152062

LOCK ASSY

LOCK, replaced by

1шт.

P35425

RIVET

replaced by

4шт.

P34707

WASHER

replaced by

4шт.

P1133865

SCREW

/BOLT, M6 x 20, replaced by

4шт.

P3143892

SHUTTER

FLAP, no longer sold

1шт.

P3443843

SHUTTER

FLAP, no longer sold

1шт.

P152062

LOCK ASSY

LOCK

1шт.

P152079

LOCK, CYLINDER

LOCK-CYLINDER

1шт.

P35425

RIVET

4шт.

P34707

WASHER

4шт.

86508568

BOLT,Hex, M6 x 1 x 16mm, Cl 8.8

BOLT, Hex, M6 x 16, Cl 8.8, Full Thd

4шт.

P1726146

REINFORCEMENT

1шт.

P4128118

CLEVIS

FORK

2шт.

P34598

SAFETY NUT

4шт.

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

BOLT, Hex, M8 x 25, 8.8

4шт.

P1722894

PLATE

4шт.

P3143891

SHUTTER

FLAP, no longer sold

1шт.

P3143882

SHUTTER

FLAP

1шт.

P152090

HANDLE

2шт.

P51947

LOCK ASSY

LOCK

2шт.

P1327934

PIN

2шт.

P3427144

SUPPORT

2шт.

P35021

WASHER

8шт.

P34598

SAFETY NUT

8шт.

P35020

WASHER

8шт.

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

BOLT, Hex, M8 x 25, 8.8

8шт.

P933890

SCREW

/BOLT, M10 x 30 x 30

4шт.

P35003

WASHER

4шт.

P852003

CATCH PLATE

CATCH

2шт.

P35002

WASHER

2шт.

P738143

COMPRESSION SPRING

COMPRESSION SPR

2шт.

P2842783

ROD

2шт.

P36391

RING, SNAP

LOCKING RING

2шт.

P34607

WASHER

2шт.

P34211

NUT

2шт.

P35002

WASHER

2шт.

P152092

LOCK ASSY

LOCK

2шт.
