Запчасти Case 220 (198) - CONTROL VALVE (07) - HYDRAULIC SYSTEM

P3128701

WASHER

2шт.

P1638101

COMPRESSION SPRING

COMPRESSION SPR

2шт.

P3128701

WASHER

2шт.

P32921

SCREW,Hex Soc Hd, M8 x 20, 10.9

/BOLT, M8 x 20

4шт.

P30405

O-RING

SEAL, 2.62 x 32.99-80

2шт.

P930007

END FITTING

2шт.

P1640401

CAP

COVER

2шт.

P1343375

VALVE POPPET

VALVE

4шт.

P943367

VALVE POPPET

VALVE

4шт.

P130486

O-RING

SEAL, 2.62 x 34.59-80

4шт.

P130486 O-ring/Seal. See NEXSB01890

1шт.

P1037450

PLUG

M33 x 1.5

4шт.

P3537725

SHIN

BRACKET

1шт.

P30405

O-RING

SEAL, 2.62 x 32.99-80

1шт.

P1145245

BACK-UP RING

JOINT, 2.18 x 21.11-90

1шт.

P30415

O-RING,0.103" Thk x 0.799" ID, -117, Cl 6, 90 Duro

SEAL, 2.62 x 20.29-80

1шт.

P30415 Seal. See EEX8007E; NIT 994

1шт.

P930474

O-RING,0.103" Thk x 0.612" ID, -114, Cl 5, 75 Duro

SEAL, 2.62 x 15.54-80

1шт.

P930474 Seal. See SAT 81

1шт.

P1637401

PLUG

1шт.

P233094

SCREW

/BOLT, M6 x 6

2шт.

P2646060

BACK-UP RING

BUSHING

2шт.

P32919

SCREW

/BOLT, M8 x 10

2шт.

P1743696

SHIN

BRACKET

1шт.

P2328851

CUPEL

2шт.

P30405

O-RING

SEAL, 2.62 x 32.99-80

1шт.

P1037449

PLUG

M30 x 1.5

1шт.

P932912

SCREW

/BOLT, M6 x 10

2шт.

P1446072

WASHER

GASKET, 11 x 6.6 x 1.6

2шт.

P1337445

PLUG

1шт.

P1429860

VALVE POPPET

VALVE

2шт.

P1038181

COMPRESSION SPRING

COMPRESSION SPR

2шт.

P30405

O-RING

SEAL, 2.62 x 32.99-80

2шт.

P930006

GUIDE

2шт.

P2543347

CARTRIDGE

1шт.

P1734524

NUT

M33 x 1.5

1шт.

P32825

SCREW

/BOLT, M8 x 25

1шт.

P34211

NUT

1шт.

P34211-Nut. See EEX4001E; SAT 71

1шт.

P30323

SEAL

3.6 x 30.8

1шт.

P930008

END FITTING

2шт.

P2328851

CUPEL

2шт.

P1838162

COMPRESSION SPRING

COMPRESSION SPR

2шт.

P738161

COMPRESSION SPRING

COMPRESSION SPR

1шт.

P1429885

VALVE POPPET

VALVE

1шт.

P1329621

PISTON

1шт.

P1446072

WASHER

GASKET, 11 x 6.6 x 1.6

1шт.

P1640440

CAP

COVER

1шт.

P1630431

O-RING,0.103" Thk x 1.424" ID, -127, Cl 5, 75 Duro

SEAL, 2.62 x 36.17-80

1шт.

P1630431-Seal. See NEXSB01890; SAT 82

1шт.

P1838159

COMPRESSION SPRING

COMPRESSION SPR

1шт.

P1429886

STOP

1шт.

P32921

SCREW,Hex Soc Hd, M8 x 20, 10.9

/BOLT, M8 x 20

6шт.

P32921 Screw/Bolt. See SAT 71

1шт.

P933005

SCREW

/BOLT

1шт.

P1640401

CAP

COVER

2шт.

P30405

O-RING

SEAL, 2.62 x 32.99-80

2шт.

P30405 O-ring. See SAT 81

1шт.
