Запчасти Case 220 (152) - CYLINDER (07) - HYDRAULIC SYSTEM

P1649526

RAM BOTTOM

1шт.

P1649526 Cylinder Base; described in Parts list as "Ram Bottom".

1шт.

P1728770

BUSHING

50 x 60 x 122

1шт.

P30348

O-RING

SEAL, 5.33 x 100.97-80, forms part of a kit

1шт.

P30343

O-RING

SEAL, 5.33 x 85.09-80, forms part of a kit

2шт.

P32822

SCREW/BOLT, M8 x 20

1шт.

P32821

SCREW/BOLT, M8 x 12

4шт.

P45023

HOLE PLUG BUTTON

BUTTON, 4.8 x 2.4

3шт.

P29137

PISTON, 52 x 95

1шт.

P30332

O-RING

SEAL, 5.33 x 50.17-80, forms part of a kit

1шт.

P29136

NUT

1шт.

P48140

CYLINDER BARREL

1шт.

P30343

O-RING

SEAL, 5.33 x 85.09-80, forms part of a kit

1шт.

P30332

O-RING

SEAL, 5.33 x 50.17-80, forms part of a kit

2шт.

P29012

BRONZE BUSH, 52 x 95

1шт.

P29110

COVER PLATE

1шт.

P46032

FELT

6 x 7, forms part of a kit

1шт.

P1849416

PISTON ROD

1шт.

P1728769

BUSHING

50 x 60 x 70

1шт.

P2546718

CYLINDER ASSY.

CYLINDER, 52 x 95

1шт.

P546046

SEAL PACKAGE

SET OF SEALS, kit number

1шт.
