Запчасти Case 220 (146) - HYDRAULIC MOTOR (07) - HYDRAULIC SYSTEM

P1123625

SHIM KIT

SET OF SHIMS, kit number

1шт.

P1249672

ASSEMBLY

forms part of a kit

1шт.

P36349

RING, SNAP

LOCKING RING

1шт.

P245444

WASHER

1шт.

P1139816

BEARING

1шт.

P36381

RING, SNAP

LOCKING RING

20шт.

P836309

RING, SNAP

LOCKING RING

20шт.

P1027962

FINGER

DOWEL

1шт.

P630413

O-RING

SEAL, 2.62 x 9.19-80, forms part of a kit

1шт.

P1230425

O-RING

10 x 140, forms part of a kit

1шт.

P130471

O-RING

4 x 530, forms part of a kit

1шт.

P36968

BRAKE

LOCKING

1шт.

P34213

NUT

1шт.

P34717

WASHER, LOCK

WASHER

12шт.

P133834

SCREW

/BOLT, M20 x 50

12шт.

P933839

SCREW

/BOLT, M10 x 35 x 35

6шт.

P933839 Screw/Bolt. See EEX8006E, EEX8006ES1; NITS 3257, 3263, 3275; SAT 84

1шт.

P34711

WASHER

6шт.

See NITS 1128, 3275

1шт.

P3330126

CAP

COVER

1шт.

P30421

O-RING

3 x 220

1шт.

P1630422

O-RING

SEAL, 3 x 214-60, forms part of a kit

1шт.

P237405

PLUG

3/4 x 12

2шт.

P30491

O-RING

2.5 x 28, forms part of a kit

2шт.

P30491 O-ring. See NEXSB 01890

1шт.

P3637779

KIT

SET

1шт.

P3030167

COVER

PLATE

1шт.

P39626

BEARING

1шт.

P1439605

BEARING

1шт.

P243786

MOTOR, HYDRAULIC

HYD. MOTOR

1шт.

P2249622

SEAL PACKAGE

SET OF SEALS, kit number

1шт.
