Запчасти Case 220 (B-073) - CONTROL VALVE (07) - HYDRAULIC SYSTEM

T1143347

VALVE

2шт.

L1343394

ASSEMBLY

2шт.

C0034916

SPRING WASHER, 25 x 12.2 x 1.5

38шт.

L0729846

PUSHER

2шт.

K0030415

SEAL, 2.62 x 20.29-80

2шт.

N0030487

SEAL, 2.62 x 37.77-80

2шт.

M0033085

SCREW/BOLT, M16 x 40

2шт.

U0034564

NUT

2шт.

V1243652

SHIN

BRACKET

1шт.

N1230443

O-RING,23.47MM ID x 2.62MM OD

SEAL, 2.62 x 23.47-80

1шт.

Z0030405

SEAL, 2.62 x 32.99-80

1шт.

N1230443

O-RING,23.47MM ID x 2.62MM OD

SEAL, 2.62 x 23.47-80

3шт.

P0940414

COVER

1шт.

J0032921

SCREW/BOLT, M8 x 20

2шт.

S1446072

WASHER

GASKET, 11 x 6.6 x 1.6

1шт.

R0532971

SCREW/BOLT, M6 x 5

1шт.

N1528891

CUPEL

1шт.

G1038157

COMPRESSION SPRING

COMPRESSION SPR

1шт.

N1528891

CUPEL

1шт.

M0929901

END FITTING

1шт.

H0030436

SEAL, 3.53 x 45.36-80

1шт.

F0930470

SEAL, 3.53 x 44.04-80

1шт.

A1743308

VALVE POPPET

VALVE

2шт.

N1443354

VALVE POPPET

VALVE

2шт.

H0036002

SPLIT PIN/SAFET, 10 x 20

2шт.

W0035762

SPLIT PIN/SAFET, 10 x 18

2шт.

V1038124

COMPRESSION SPRING

COMPRESSION SPR

2шт.

R0030444

2.5 x 15

2шт.

R0532971

SCREW/BOLT, M6 x 5

1шт.

J0032921

SCREW/BOLT, M8 x 20

2шт.

S1446072

WASHER

GASKET, 11 x 6.6 x 1.6

1шт.

P0940414

COVER

1шт.

F0930470

SEAL, 3.53 x 44.04-80

1шт.

H0030436

SEAL, 3.53 x 45.36-80

1шт.

M0929901

END FITTING

1шт.

W2028781

SPACER

1шт.

N1528891

CUPEL

1шт.

H1038158

COMPRESSION SPRING

COMPRESSION SPR

1шт.

N1528891

CUPEL

1шт.
