Запчасти Case 160CKS (087) - TRACK GROUP (04) - UNDERCARRIAGE

P3227346

ROD

2шт.

P3227346 Rod. Retired part.

1шт.

P933893

SCREW

/BOLT, M20 x 1.5 x 120

8шт.

P5428789

WASHER

21 x 7 x 35

8шт.

P1220315

TRAVERSE

2шт.

P1822978

PLATE

4шт.

P4046030

SEAL

2шт.

P2046007

WIPER SEAL

SEAL, 90 x 100

2шт.

P1729820

PISTON

2шт.

P143386

VALVE POPPET

VALVE

2шт.

P30402

O-RING

2.5 x 22.5

2шт.

See NITS 3208, 3260 10/18/96

1шт.

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

2шт.

See NEXSL00189, SAT 65, NIT 3260

1шт.

814-20140

BOLT,Hex, M20 x 2.5 x 140mm, Cl 8.8

4шт.

832-10420

NUT,M20 x 2.5, Cl 8

NUT, LOCK, , Safety M20 x 2.5, Cl 8

4шт.

P23033

PLATE, M24 x 3, no longer exists on new model

36шт.

P23033 Plate. Retired Part

1шт.

P4528704

WASHER

25 x 17 x 45

72шт.

P133809

SCREW

/BOLT, M24 x 150, no longer exists on new model

150шт.

P133801

SCREW

/BOLT, M24 x 130

130шт.

P1033077

SCREW

/BOLT, 3/4-16 UNF x 70

408шт.

See NEXSB 02490

1шт.

P234504

NUT

408шт.

See NEXSB 02490

1шт.

P1742368

TRACK SHOE

PAD

102шт.
