Запчасти Case 160CKS (083) - TRACK GROUP (04) - UNDERCARRIAGE

P927386

PUSHER

2шт.

P33857

SCREW

/BOLT, M16 x 100

8шт.

P33857 Screw/Bolt. See 814-16100 Bolt. P143386 Valve subs to O-ring P/N. (QTY): P146233 Seat (1); P30402 O-ring (1); P31005 Steel Ball (1); P328782 Washer (1); P35713 Roll Pin (1); P38169 Spring (1); P45801 Grease Fitting (1); P30402 O-ring See NITS 3208, 3260 P45801, Grease Fitting See NEXSL00189, SAT 65, NIT3260, P653716-Shock Absorber See NIT 947. P242367-Pad subs to P1842356 Pad, 28"

1шт.

P34715

WASHER, LOCK

WASHER

8шт.

P2023498

TRAVERSE

2шт.

P33875

SCREW

/BOLT, M16 x 70, part not sold under assembly reference number

4шт.

P35006

WASHER

part not sold under assembly reference number

8шт.

P134547

SAFETY NUT

part not sold under assembly reference number

4шт.

P133802

SCREW

/BOLT, M16 x 40, part not sold under assembly reference number

4шт.

P34715

WASHER, LOCK

WASHER, part not sold under assembly reference number

4шт.

P4046030

SEAL

2шт.

P2046007

WIPER SEAL

SEAL, 90 x 100

2шт.

P1227337

PISTON

2шт.

P143386

VALVE POPPET

VALVE

2шт.

P30402

O-RING

2.5 x 22.5

2шт.

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

2шт.

P2228754

BUSHING, 125 x 140 x 115

2шт.

P1436936

SPRING WASHER

2шт.

P653716

SHOCK ABSORBER

no longer sold

2шт.

P133820

SCREW/BOLT, M22 x 160

4шт.

P34718

WASHER, LOCK

WASHER

8шт.

P34122

NUT

4шт.

P23033

PLATE, M24 x 3

28шт.

P34719

WASHER, LOCK

WASHER

56шт.

P833815

SCREW

/BOLT, M24 x 120

56шт.

P1642317

TRACK SHOE

PAD

98шт.

P242366

PAD, no longer sold

98шт.

P942380

TRACK SHOE

PAD

98шт.

P242367

TRACK SHOE

PAD

98шт.

P342309

PAD

98шт.

P233006

SCREW

/BOLT, 3/4-16UNF x 56

392шт.

P234504

NUT

392шт.
