Запчасти Case 160CK (218) - CONTROL VALVE (07) - HYDRAULIC SYSTEM

Схема запчастей Case 160CK - (218) - CONTROL VALVE (07) - HYDRAULIC SYSTEM

Артикул

Название

Примечание

Количество

P1143347

VALVE

2шт.

P1343394

ASSEMBLY

2шт.

P34916

RUBBER WASHER

SPRING WASHER, 25 x 12.2 x 1.5

38шт.

P729846

PUSHER

2шт.

P30415

O-RING,0.103" Thk x 0.799" ID, -117, Cl 6, 90 Duro

SEAL, 2.62 x 20.29-80, forms part of a kit

2шт.

P30487

O-RING,0.103" Thk x 1.487" ID, -128, Cl 5, 75 Duro

SEAL, 2.62 x 37.77-80, forms part of a kit

2шт.

P33085

SCREW

/BOLT, M16 x 40

2шт.

P34564

NUT

2шт.

P1243652

SHIN

BRACKET

1шт.

P1230443

O-RING

SEAL, 2.62 x 23.47-80, forms part of a kit

1шт.

P30405

O-RING

SEAL, 2.62 x 32.99-80, forms part of a kit

1шт.

P1230443

O-RING

SEAL, 2.62 x 23.47-80, forms part of a kit

3шт.

P1743308

VALVE POPPET

VALVE

2шт.

P1443354

VALVE POPPET

VALVE, no longer sold

2шт.

P36002

SPLIT PIN/SAFETY, 10 x 20

2шт.

P35762

SPLIT PIN/SAFETY PIN

SPLIT PIN/SAFETY, 10 x 18

2шт.

P1038124

SPRING COMPRESSOR

COMPRESSION SPRING

2шт.

P30444

O-RING,2.5mm Thk x 15mm ID, 80 Duro

2.5 x 15

2шт.

P940414

CAP

COVER

1шт.

P32921

SCREW,Hex Soc Hd, M8 x 20, 10.9

/BOLT, M8 x 20

2шт.

P1446072

WASHER

GASKET, 11 x 6.6 x 1.6, forms part of a kit

1шт.

P532971

SCREW

/BOLT, M6 x 5

1шт.

P1528891

CUPEL

1шт.

P1038157

SPRING COMPRESSOR

COMPRESSION SPRING

1шт.

P1528891

CUPEL

1шт.

P929901

END FITTING

1шт.

P30436

O-RING

SEAL, 3.53 x 45.36-80

1шт.

P930470

O-RING,0.139" Thk x 1.734" ID, -224, Cl 6, 90 Duro

SEAL, 3.53 x 44.04-80

1шт.

P930470

O-RING,0.139" Thk x 1.734" ID, -224, Cl 6, 90 Duro

SEAL, 3.53 x 44.04-80

1шт.

P30436

O-RING

SEAL, 3.53 x 45.36-80

1шт.

P929901

END FITTING

1шт.

P2028781

SPACER

1шт.

P1528891

CUPEL

1шт.

P1038158

SPRING COMPRESSOR

COMPRESSION SPRING

1шт.

P1528891

CUPEL

1шт.

P532971

SCREW

/BOLT, M6 x 5

1шт.

P32921

SCREW,Hex Soc Hd, M8 x 20, 10.9

/BOLT, M8 x 20

2шт.

P1446072

WASHER

GASKET, 11 x 6.6 x 1.6, kit of x identical parts

1шт.

P940414

CAP

COVER

1шт.

P1243651

SHIN

BRACKET

1шт.

P2249635

SEAL PACKAGE

SET OF SEALS, kit number

1шт.

Выбрано товаров: 41
