Запчасти Case 160CK (217) - CONTROL VALVE (07) - HYDRAULIC SYSTEM

P1143347

VALVE

2шт.

P1343394

ASSEMBLY

2шт.

P34916

RUBBER WASHER

SPRING WASHER, 25 x 12.2 x 1.5

8шт.

P729846

PUSHER

2шт.

P30415

O-RING,0.103" Thk x 0.799" ID, -117, Cl 6, 90 Duro

SEAL, 2.62 x 20.29-80

2шт.

P30487

O-RING,0.103" Thk x 1.487" ID, -128, Cl 5, 75 Duro

SEAL, 2.62 x 37.77-80

2шт.

P33085

SCREW

/BOLT, M16 x 40

2шт.

P34564

NUT

2шт.

P1643647

SHIN

BRACKET

1шт.

P30325

SEAL,0.139" Thk x 1.359" ID, -220, Cl 5, 75 Duro

3.6 x 34.1

1шт.

P30318

O-RING

SEAL, 3.6 x 23

4шт.

P30310

SEAL

2.7 x 12.1

2шт.

P1038124

SPRING COMPRESSOR

COMPRESSION SPRING

2шт.

P36002

SPLIT PIN/SAFETY, 10 x 20

2шт.

P1743308

VALVE POPPET

VALVE

2шт.

P30444

O-RING,2.5mm Thk x 15mm ID, 80 Duro

2.5 x 15

2шт.

P2446237

PISTON

1шт.

P1446041

SEAL

1шт.

P1540429

CAP

COVER

1шт.

P532961

SCREW

/BOLT, M6 x 67

3шт.

P1446041

SEAL

1шт.

P1540428

CAP

COVER

1шт.

P2028758

SPACER

1шт.

P1145465

WASHER

1шт.

P729760

END FITTING

1шт.

P1145465

WASHER

1шт.

P1038147

COMPRESSION SPRING

1шт.

P1038148

SPRING COMPRESSOR

COMPRESSION SPRING

1шт.

P32910

SCREW

/BOLT, M6 x 16

3шт.

P1540429

CAP

COVER

1шт.

P1446041

SEAL

1шт.

P2446237

PISTON

1шт.

P1643646

SHIN

BRACKET

1шт.
