Запчасти Case 160CK (216) - CONTROL VALVE (07) - HYDRAULIC SYSTEM

P1143328

VALVE

2шт.

P1443393

ASSEMBLY

2шт.

P429891

GUIDE

2шт.

P34921

RUBBER WASHER

SPRING WASHER, 28 x 14.2 x 2.2

28шт.

P929812

PUSHER

2шт.

P30460

O-RING,0.103" Thk x 0.987" ID, -120, Cl 5, 75 Duro

SEAL, 2.62 x 25.07-80

2шт.

P30497

O-RING

3 x 41

2шт.

P33085

SCREW

/BOLT, M16 x 40

2шт.

P34564

NUT

2шт.

P1643647

SHIN

BRACKET

1шт.

P1540429

CAP

COVER

2шт.

P2446237

PISTON

2шт.

P1446041

SEAL

3шт.

P1540428

CAP

COVER

1шт.

P1145465

WASHER

2шт.

P2028758

SPACER

2шт.

P1038148

SPRING COMPRESSOR

COMPRESSION SPRING

1шт.

P1038147

COMPRESSION SPRING

1шт.

P729760

END FITTING

1шт.

P532961

SCREW

/BOLT, M6 x 67

3шт.

P1243629

SHIN

BRACKET, no longer sold

1шт.

P30325

SEAL,0.139" Thk x 1.359" ID, -220, Cl 5, 75 Duro

3.6 x 34.1

1шт.

P30318

O-RING

SEAL, 3.6 x 23

5шт.

P30310

SEAL

2.7 x 12.1

2шт.

P1038124

SPRING COMPRESSOR

COMPRESSION SPRING

2шт.

P36002

SPLIT PIN/SAFETY, 10 x 20

2шт.

P1143327

VALVE POPPET

VALVE

2шт.

P30313

SEAL

2.7 x 16.9

2шт.

P2446237

PISTON

1шт.

P1446041

SEAL

1шт.

P940402

COVER

1шт.

P532961

SCREW

/BOLT, M6 x 67

3шт.

P1446041

SEAL

1шт.

P940401

COVER

1шт.

P2028758

SPACER

1шт.

P1145465

WASHER

1шт.

P729707

END FITTING

1шт.

P1145465

WASHER

1шт.

P1038147

COMPRESSION SPRING

1шт.

P1038148

SPRING COMPRESSOR

COMPRESSION SPRING

1шт.

P32910

SCREW

/BOLT, M6 x 16

3шт.

P940402

COVER

1шт.

P1446041

SEAL

1шт.

P2446237

PISTON

1шт.

P1643646

SHIN

BRACKET

1шт.

P1243628

SHIN

BRACKET, no longer sold

1шт.
