Запчасти Case 160CK (176) - CYLINDER (07) - HYDRAULIC SYSTEM

Схема запчастей Case 160CK - (176) - CYLINDER (07) - HYDRAULIC SYSTEM

Артикул

Название

Примечание

Количество

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

1шт.

P836976

SPECIAL RING

SPRING WASHER

1шт.

P27362

PIN

1шт.

P6846053

BAND

STRIP, forms part of a kit

1шт.

P646038

SPECIAL MAT. SEAL

SEAL, forms part of a kit

2шт.

P6846053

BAND

STRIP, forms part of a kit

1шт.

P929757

NUT

1шт.

P4246023

BACK-UP RING

JOINT, 4.65 x 89.48-90, forms part of a kit

2шт.

P30344

O-RING

SEAL, 5.33 x 88.27-80, forms part of a kit

1шт.

P9749362

JACK BODY

CYLINDER

1шт.

P1928613

BUSHING

75 x 100 x 110

1шт.

P1345275

BACK-UP RING

JOINT, part not sold under assembly reference number

1шт.

P1345276

BACK-UP RING

JOINT, part not sold under assembly reference number

1шт.

P2746023

SEGMENT

forms part of a kit

3шт.

P2630123

CAP

COVER

1шт.

P1730426

O-RING

SEAL, 5.33 x 151.77-80, forms part of a kit

1шт.

P6846017

BACK-UP RING

JOINT, 4.65 x 153.11-90, forms part of a kit

1шт.

P1629088

CYLINDER END CAP

BEARING

1шт.

P651262

SEAL

forms part of a kit

1шт.

P2046008

WIPER SEAL

SEAL, 110 x 120, forms part of a kit

1шт.

P532917

SCREW

/BOLT, M18 x 60

18шт.

P7249471

PISTON ROD

ROD

1шт.

P1928613

BUSHING

75 x 100 x 110

1шт.

P3649680

SEAL PACKAGE

SET OF SEALS, kit number

1шт.

P6646736

CYLINDER ASSY.

CYLINDER, 110 x 165

1шт.

Выбрано товаров: 25
