Запчасти Case 160CK (168) - CYLINDER (07) - HYDRAULIC SYSTEM

Схема запчастей Case 160CK - (168) - CYLINDER (07) - HYDRAULIC SYSTEM

Артикул

Название

Примечание

Количество

P9249323

JACK BODY

CYLINDER

1шт.

P1928603

BUSHING

60 x 75 x 90

1шт.

P27362

PIN

1шт.

P129186

NUT

1шт.

P30338

O-RING

SEAL, 5.33 x 69.22-80, forms part of a kit

1шт.

P828873

WASHER

1шт.

P51970

SPECIAL RING

SPRING WASHER

1шт.

P2746014

SEGMENT

forms part of a kit

1шт.

P2746012

SEAL

no longer sold

1шт.

P1051185

SEAL

135 x 110 x 25.5, forms part of a kit

1шт.

P2746014

SEGMENT

forms part of a kit

1шт.

P7330165

CYLINDER END CAP

BEARING

1шт.

P2746013

SEGMENT

forms part of a kit

1шт.

P4646042

BACK-UP RING

JOINT, 5.99 x 125.20-90, forms part of a kit

1шт.

P30356

O-RING

SEAL, 6.99 x 123.19-80, forms part of a kit

1шт.

P532928

SCREW

/BOLT, M16 x 110

14шт.

P1351215

SEAL

forms part of a kit

1шт.

P2746013

SEGMENT

forms part of a kit

1шт.

P3330101

WASHER

1шт.

P2046007

WIPER SEAL

SEAL, 90 x 100, forms part of a kit

1шт.

P6849485

STEM

ROD

1шт.

P1928603

BUSHING

60 x 75 x 90

1шт.

P3849618

SEAL PACKAGE

SET OF SEALS, kit number

1шт.

P6546734

CYLINDER ASSY.

CYLINDER

1шт.

Выбрано товаров: 24
