Запчасти Case 160CK (141) - HYDRAULIC MOTOR (07) - HYDRAULIC SYSTEM

P1123621

SHIM KIT

SET OF SHIMS, kit number

1шт.

P3330124

CAP

COVER

1шт.

P34709

WASHER

6шт.

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

BOLT, Hex, M8 x 25, 8.8

6шт.

P39925

BEARING

no longer sold

1шт.

P1639937

BEARING

1шт.

P1249673

ASSEMBLY

forms part of a kit, replaced by

1шт.

P30441

O-RING

3 x 190, forms part of a kit

1шт.

P3446030

OIL SEAL

SEAL RING, 140 x 110 x 12

1шт.

P36342

RING, SNAP

LOCKING RING

1шт.

P145461

WASHER

1шт.

P36380

RING, SNAP

LOCKING RING

20шт.

P836308

RING, SNAP

LOCKING RING

20шт.

P237405

PLUG

3/4 x 12

2шт.

P30491

O-RING

2.5 x 28, forms part of a kit

2шт.

P39633

BEARING

1шт.

P1230404

O-RING

4 x 489, forms part of a kit

1шт.

P130494

O-RING

10 x 120, forms part of a kit

1шт.

P1628927

BUSHING

1шт.

P34709

WASHER

1шт.

P32920

SCREW

/BOLT, M8 x 16

1шт.

P3030150

COVER PLATE

1шт.

P1146192

GUIDE

1шт.

P34711

WASHER

2шт.

P32931

SCREW

/BOLT, M10 x 20

2шт.

P1523415

BRACKET

1шт.

P35722

SPLIT PIN/SAFETY PIN

SPLIT PIN, 8 x 30

2шт.

P34709

WASHER

1шт.

P132909

SCREW

/BOLT, M8 x 35

1шт.

P133833

SCREW

/BOLT, M20 x 40

8шт.

P34717

WASHER, LOCK

WASHER

8шт.

P2249661

SEAL PACKAGE

SET OF SEALS, kit number

1шт.

P1943742

MOTOR

1шт.

P243778

HYD. MOTOR, no longer sold

1шт.
