Запчасти Case 115CL (173) -

1

P1754636

SHELL

2шт.

3

P245381

WASHER, 46 x 75 x 2

8шт.

4

P50073

SHAFT LOCK

4шт.

5

P35962

BUSHING

40 x 50 x 35

8шт.

6

P29417

BUSHING

40 x 50 x 70

4шт.

7

P30950

HEADED PIN

PIN, HEADED

4шт.

8

P35005

WASHER

4шт.

9

P35510

SPLIT PIN

2 x 20

4шт.

10

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

4шт.

11

P853134

LINKAGE YOKE

YOKE

1шт.

13

P35975

BUSHING

55 x 70 x 48

2шт.

14

P35993

BUSHING,M40 x 50 x 28

40 x 50 x 28

8шт.

15

P50347

HANDLED SHAFT

PIN

4шт.

16

P28478

WASHER

65 x 41 x 4

4шт.

17

P35557

SPLIT PIN

8 x 80

4шт.

18

P1754637

ARM

2шт.

20

P29153

SHAFT LOCK

2шт.

21

P28767

BUSHING

40 x 55 x 45

4шт.

22

P50346

HEADED PIN

PIN

2шт.

23

P30859

BOLT

SCREW/BOLT

2шт.

24

P34714

WASHER, LOCK

WASHER

2шт.

25

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

4шт.

1

P1745624

2шт.

3

P245381

WASHER, 46 x 75 x 2

8шт.

4

P50073

SHAFT LOCK

4шт.

5

P35962

BUSHING

40 x 50 x 35

8шт.

6

P29417

BUSHING

40 x 50 x 70

4шт.

7

P30950

HEADED PIN

PIN, HEADED

4шт.

8

P35005

WASHER

4шт.

9

P35510

SPLIT PIN

2 x 20

4шт.

10

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

4шт.

11

P1754622

LINKAGE YOKE

YOKE

1шт.

13

P35975

BUSHING

55 x 70 x 48

2шт.

14

P35993

BUSHING,M40 x 50 x 28

40 x 50 x 28

8шт.

15

P50347

HANDLED SHAFT

PIN

4шт.

16

P28478

WASHER

65 x 41 x 4

4шт.

17

P35557

SPLIT PIN

8 x 80

4шт.

18

P1754623

ARM

2шт.

20

P29153

SHAFT LOCK

2шт.

21

P28767

BUSHING

40 x 55 x 45

4шт.

22

P50346

HEADED PIN

PIN

2шт.

23

P30859

BOLT

SCREW/BOLT

2шт.

24

P34714

WASHER, LOCK

WASHER

2шт.

25

J45801

LUBE NIPPLE,M8 x 1.25

GREASE NIPPLE, M8 x 1.25

4шт.
